For ducts measuring 400 - 1200mm (15.7 - 47.2"); Continuous rotation speed adjustment, 225 - 880 rpm
The Hydmaster is the most powerful HVAC electrical brushing machine designed for demanding cleaning practices within industrial sized buildings such as factories, power plants, and mills. The Lifa Hydmaster performs the most strenuous tasks using hydraulic power. The Hydmaster brush speeds past the competition with a rotating speed of 225 - 880 r/min. It operates on monophase voltage, which means the Hydmaster is quieter than other pneumatic cleaning machines. The Lifa Hydmaster cleans 75 meters (246 ft.) of duct when extended in both directions from one access hatch and its oversize brushes can rotate in narrow ducts.
The Lifa Hydmaster is a versatile brush-cleaning machine with a hydraulic drive for demanding industrial and commercial cleaning applications that need exceptional force. Hydmaster’s special features are the built-in camera and the hydraulic propulsion power produced by normal single phase electricity.
The machine uses environmentally friendly, synthetic and biodegradable oil. The hydraulic tubes have a laminated, durable nylon fiber interior making the Hydmaster the most durable brushing machine on the market.
The force that rotates the brush is produced hydraulically along the flexible shaft. The built-in hydraulic pump provides an alternative to large, expensive, noisy, and non-user friendly pneumatic cleaning machines that use compressors. The Hydmaster operates on single phase voltage (240 VAC or 110-120 VAC) and is distinctly quieter than air-jetting machines using compressed air. This makes the Hydmaster extremely easy to carry and use.
The Hydmaster model that comes with a video camera monitors the effects and results of the cleaning that is being performed. The monitor also offers the ability to see any potential obstacles that may prove to be a nuisance. The video camera also monitors silencers and sound attenuators, which are used for noise control. In addition, the camera can also monitor automatic and manual air volume, as well as, other control apparatus of the ventilation system. Using the video camera monitor enables you to avoid unexpected problems and can save you from a lot of frustrating headaches.
The Lifa Hydmaster is designed for both rectangular and round ventilation ducts ranging from 400 - 1200mm (15.7 - 47.2"). The rotating speed is adjustable from 225 to 880 r/min. When set to maximum, Lifa Hydmaster’s torque, otherwise known as brushing force, is more powerful than that of any other cleaning machine. The machine can then rotate its oversized brush in narrow and smaller size ducts. You won’t have to change brushes as often with the Hydmaster, as you do with other machines. It also has and can be used, with Lifa’s specific written approval, for many other purposes (e.g. cleaning of accumulated dirt and sediment from different process pipes).
The Hydmaster is Lifa’s flagship product and is protected by a patent.
Lifa Y-Gear (accessory) gives an extra cleaning force for the corners in rectangular ducts.
- The strongest cleaning machine on the market by far
- 40-metre (131 ft.) range cleaning axis/shaft
- For large ducts: ranging from 400 - 1200mm (15.7 - 47.2")
- Max. torque 10 Nm (7.4 ft-lbs)
- Adjustable brush rotation speed 225 - 880 rpm
- Pneumatic foot pedal for operating and changing direction of brush rotation
- Wheel mounted for easy mobility
- Operates on single-phase current (normal plug-in electricity)
Lifa Air's brushing machines are designed and built to meet the real needs of HVAC duct cleaning professionals. Round and rectangular ducts can be cleaned with either mechanical brushing and negative pressurizing or by combining these with simultaneous use of pressurized air or chemicals. Lifa Air manufactures a range of brushing machines with either electric, hydraulic or pneumatic operation of which many are also suitable for grease duct cleaning.
HVAC ducts must be cleaned regularly in order to maintain a healthy indoor air and to avoid risk factors, such as accumulated grease in the restaurant environments which may catch fire.
Lifa's brushing machines are the result of long and dedicated R&D work. Continuous updates based upon innovation and manufacturing improvements together with customer feedback ensures user friendliness and long term efficient machinery. Maintaining the cleanliness of HVAC ductwork has never been this easy!
